HWHR provides the following synthesized forms; users may freely synthesize according to respective experimental and working needs; please contact us if you have specific requests.
Assembly Example 1
Adjustment Dimension：XYZ Three-Dimensional Travel Range: XY: 25mm Z: 13mm Including: BP25-2C Manual Linear Stages Two BS13-1 Manual Linear Stages One DB-1 Base Plate One
Assembly Example 2
Adjustment Dimension：XYZThree-Dimensional Travel Range: XY: 25mm Z: 5mm Including: BP25-2C Manual Linear Stages Two BS5-1C Manual Linear Stages One DB-11 Base Plate One DB-1 Base Plate One
Assembly Example 3
Adjustment Dimension：XYθThree-Dimensional Travel Range: XY: 25mm θ: 360° Including: BP25-2C Manual Linear Stages Two BR82-1C Manual Linear Stages One DB-1 Base Plate One
Assembly Example 4
Adjustment Dimension：XYZθT Six-Dimensional Travel Range: XY: 25mm Z: 5mm θ: 360° T: Two-Dimensional±5° Including: BP25-2C Manual Linear Stages Two BS5-1C Lab Jack One BR82-1C Manual Rotation Stage One BT211C Two-Axis Tilt Platform One DB-1 Base Plate One
Assembly Example 5
Adjustment Dimension：XYZTFive -Dimensional Travel Range：XYZ：25mm T：Two-Dimensional±2o Including: BP25-5C Manual Integrated Two-Dimensional linear stage One BP25-2C Manual Linear Stages One BT301 Multi-Axis Tilt Platform One DZ-4 Angle Bracket90° two
Assembly Example 6
Adjustment Dimension：XYZθFour -Dimensional Travel Range：XY：13mm Z：5mm θ：360o Including: BP13-1C Manual Linear Stages 二个 BR25-1CManual Rotation Stage One BS5-1VPrecision Lab Jack One DB10 Base Plate One
Assembly Example 7
Adjustment Dimension：XYTwo-Dimensional Travel Range: XY: 25mm Including: BP25-1C Manual Linear Stages Two DB-1 Base Plate One
Assembly Example 8
Adjustment Dimension：Two-Dimensional Rotation Travel Range: θx: ±30° θy: ±15° Including: BG102 Goniometer One BG103 Goniometer One
Assembly Example 9
Adjustment Dimension：XYTwo-Dimensional Travel Range:Two-Dimensional 13mm Including: BP13-1C Manual Linear Stages Two DB-10 Base Plate One
Assembly Example 10
Adjustment Dimension：X YTwo-Dimensional Travel Range: Two-Dimensional 13mm Including: BP13-2C Manual Linear Stages Two DB-10 Base Plate One
Assembly Example 11
Adjustment Dimension：XYTwo-Dimensional Travel Range: Two-Dimensional 25mm Including: BP25-2C Manual Linear Stages Two DB-1 Base Plate One
Assembly Example 12
Adjustment Dimension：XYTwo-Dimensional Travel Range：Two-Dimensional 25mm Including: BP25-3C Manual Linear Stages Two DB-1 Base Plate One
Assembly Example 13
Adjustment Dimension：XYZThree-Dimensional Travel Range：Three-Dimensional 13mm Including: BP13-1C Manual Linear Stages Three DZ-5 Angle Bracket One DB-10 Base Plate One
Assembly Example 14
Adjustment Dimension：XYZThree-Dimensionall Travel Range：Three-Dimensional 13mm Including: BP13-2C Manual Linear Stages Three DZ-5 Angle Bracket One DB-10 Base Plate One
Assembly Example 15
Adjustment Dimension：XYZThree-Dimensional Travel Range: Three-Dimensional 25mm Including: BP25-2C Manual Linear Stages Three DZ-4 Angle Bracket One DB-1 Base Plate One
Assembly Example 16
Adjustment Dimension：XYZThree-Dimensional Travel Range: Three-Dimensional 25mm Including: BP25-3C Manual Linear Stages Three DZ-1 Angle Bracket One DB-1 Base Plate One
